| Spindle Pitch |
200 mm |
| Machine Width |
3 Feet |
| Machine Height |
6'-7" Feet |
| Spindle in Section |
32 nos |
| Spindle Pot |
90/110 mm dia mm dia Hard Anodies & Plazma Cotting & S.S. |
| Feed Tensioner |
Boll Ceramic |
| Over Feed |
Excellent Self Design Suitable for cops Winding |
| Take up Traversing |
Common suitable for cylindrical or Bioconical |
| Count & Range |
40 to 300 & Multiply Yarn |
| Viable Twist Range |
300 TPM to 1200 TPM |
| Spindle RPM |
Up to 16000 (MECHANICAL SPEED) |
| Feed Bobbin |
32 x 36 x 240/270 & 38 x 42 x 240 Alluminium / Plastic Tubes up 105 mm Dia |
| Yarn Take up speed |
Up to 60 Met/ Min |
| Take up Package |
On spring pressure Hinge Creadle |
| Cone & Tube |
End cap size 68 x 28 to 46 x 18 x 170 mm cone / cheese 57/69 x 170 mm |
| Caintain |
2.5 KG |
| Display |
RPM / TPM. Met/Min |
