| Spindle Pitch |
220 mm |
| Machine Width |
3 Feet |
| Machine Height |
5'-1" Feet |
| Spindle in Section |
12 nos |
| Spindle Pot |
120 mm dia mm dia Hard Anodies & Plazma Cotting & S.S. |
| Feed Tensioner |
Boll Ceramic & spring capsual |
| Over Feed |
Excellent Self Design Suitable for cone winding |
| Take up Traversing |
Common suitable for cylindrical or Bioconical Gear Box |
| Count & Range |
20 to 100 Multiply yarn |
| Viable Twist Range |
12 TPI to 90 TPI |
| Spindle RPM |
Up to 10000 (MECHANICAL SPEED) |
| Feed Bobbin |
32 x 36 x 170 mm & 38 × 42 x 170 Alluminium / plastic Tubes up to 116 Dia |
| Yarn Take up speed |
Up to 60 Met/ Min |
| Take up Package |
On spring pressure spring strip Creadle without auto lifting system |
| Cone & Tube |
End cap size 68 × 28 to 46 × 18 × 170 mm cone / cheese 57 × 69 × 170 mm |
| Caintain |
2 KG |
| Display |
RPM / TPM. Met/Min |
