| Spindle Pitch |
260 mm |
| Machine Width |
3 Feet |
| Machine Height |
5'-1" Feet |
| Spindle in Section |
12 nos |
| Spindle Pot |
150 mm dia mm dia Hard Anodies & Plazma Cotting & S.S. |
| Feed Tensioner |
Boll Ceramic & spring capsual |
| Over Feed |
Excellent Self Design Suitable for cone winding |
| Take Up Traversing |
Common suitable for cylindrical or Bioconical Gear Box |
| Count & Range |
15 to 30 Multy Play Yarn |
| Viable Twist Range |
7 TPI to 65 TPI |
| Spindle RPM |
Up to 8500 ( MECHANICAL SPEED ) |
| Feed Bobbin |
32 x 36 x 170 mm & 38 × 42 x 170 & 43 × 49 x 170Alluminium / plastic, Tubes up to 135 Dia |
| Yarn Take up speed |
Up to 60 Met/ Min |
| Take up Package |
On spring pressure spring strip without Creadle auto lifting system |
| Cone & Cube |
End cap size 68 × 28 to 46 × 18 × 170 mm cone / cheese 57 × 69 × 170 mm |
| Caintain |
2 KG |
| Display |
RPM / TPM. Met/Min |
| |
With Foot Brack System |
